    Short Manual Probe Ultrasonic Hardness Tester , Durometer Testing Equipment

    Ask Lasest Price
    Brand Name : Sinowon
    Model Number : SU-340T
    Certification : CE
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50pcs per month
    Delivery Time : 15days
    • Product Details
    • Company Profile

    Short Manual Probe Ultrasonic Hardness Tester , Durometer Testing Equipment

    Short Manual Probe Ultrasonic Hardness Tester , Durometer Testing Equipment

    UCI hardness test—a hardness testing method using a calibrated instrument by pressing a resonating rod with a defined indenter, for example, a Vickers diamond, with a fixed force against the surface of the part to be tested.


    Application:

    SU-340T equips with short probe, it can non-destructively measure hardness of internal wall of tube, also called Tube Hardness Tester,Inner Wall Hardness Tester.


    Specification:


    NameShort Manual Probe Ultrasonic Hardness Tester
    ModelSU-340T
    Code#882-141T
    Optional Probe20N:HP-2T
    Range(DIN)

    HRC:20-68;HRB:55-100;HRA:37-85;

    HBS:100-500;HV:100-1500;Mpa:255-2180N/mm


    Accuracy(%)

    Scale﹤250HV250~500HV500~800Hv﹥800HV
    HV0.16789
    HV0.36789
    HV0.85567
    HV15567
    HV55555
    HV105555
    Hardness Scales(HV);(HRA,HRB,HRC);(HB);(HS)
    Screen3.2“ Color LCD
    Data Display

    Loading force,Testing-times, Testing result, Average,

    Maximum,Minimum,Deviation and Conversion scale.

    LanguageChinese, English, German, Portugese, Turkish
    Data OutputRS232 Hyper Terminal/Bluetooth Printer
    Data StorageTo save 1000-groups of measuring data and 20-groups of calibration data
    Word InputLetters and numerals
    Working EnvironmentTemperature: -10°C to 50°C ; Humidity :30%-80% R.H.
    Battery VoltageRechargeable lithium battery ; Voltage :4.2V, 4800mAh
    Recharger VoltageAC220V/50Hz, 110V/60Hz
    Main unit Dimension and WeightMain unit Dimension :160 x 80 x 30mm (L x W x H);Manual Probe:Φ22×153mm ; Weight(No Probe): 0.5Kg
    Packing Dimension and WeightPacking Dimension :320 x 430 x 155mm (L x W x H) ; Packing Weight (Standard Delivery):4.3Kg


    T = Piezo Transducer
    R = Receiver
    O = Oscillating rodV = indenter, for example, Vickers diamond m = test material
